For simple projects, it’s easy enough to type gcc -o kernel kernel.c at the command line, but when you’re compiling dozens of files with gobs of compiler and linker options, it helps to have some automation. Probably the most widely used tool for automating C project builds is Make. I used Make for a while, but I’ve since switched to tup, and have been much happier.

Life With Make

I started out building my project using Make, and stuck with it for about 4 months. When my project was simple (i.e., just the bootloader), Make worked great. I downloaded a short Makefile from this guy’s excellent UEFI tutorial (this tutorial essentially single-handedly resulted in me compiling my first UEFI application) that specified the compiler and linker flags, and ran a few commands on the source files. Everything was peachy.

Fast-forward a few weeks – I’d written a bootloader and was starting on the kernel. The kernel is really a separate project from the bootloader – it needed different compiler/linker flags, required different linked in libraries and included headers, and ends up as a separate binary. However, I wanted the two projects to be in the same Git repository, and I wanted a single invocation of make from the project root to build both projects. After some Googling, I patched together a set of recursive Makefiles that fulfilled my needs, and things were good again. Then I noticed that when I made a change to a .h file, it wasn’t recompiling the source files that depended on that header. This resulted in a lot of make clean && make, which felt like overkill. More Googling. More tweaking of Makefiles. Fixed this as well. Perfect. For the moment.

The final straw for me was when I was working on including the ACPICA library (an external library, written by Intel, used to interpret the ACPI tables. There will be at least one article on the mess that is ACPI later.) I put the code for this library in a subdirectory in my project, and attempted to compile it in with the rest of my code. Because it needed different compiler flags than the rest of my kernel (it wouldn’t compile with -Werror, for example) I had a Makefile specifically to build ACPICA. I struggled, however to get the dependencies all correct – I would frequently have to make clean && make to make a change to the ACPICA code visible to the rest of the project. While I have no doubts that all of my issues were caused by my own ignorance and that I could have solved my problems with a bit more Googling, I decided that it was time for a change.

Life After Make

After struggling with a few other systems (that appeared to offer few benefits over make), I stumbled upon tup. For me tup has a few distinct advantages:

It works recursively by default. When you run tup from any directory in your project, it automatically scans every subdirectory in the project and executes in every directory with a Tupfile. This means you have to have one Tupfile per code directory, but I’ve found that this is hardly difficult, and it gives you the ability to easily change the compilation options for every submodule in your project.
tup keeps track of all the files opened by every command executed in your Tupfile to automatically determine dependencies. For example, a line like hello.c |> gcc -o %o %f |> hello means take the file hello.c, and invoke the command gcc -o hello hello.c to produce the file hello. If hello.c includes hello.h, gcc will open hello.h during compilation, tup will “see” this, and it will implicitly determine that hello.c depends on hello.h. If you subsequently make a change to hello.h, tup will automatically recompile all files that depend on it.
tup builds up a full graph of all file dependencies and uses this graph to determine which files to recompile during a build. From my experience, tup has done a very good job of only recompiling the necessary files when I make a change.

Overall, I have been very happy with tup. It only took me an hour or so to set up, seems to understand my project dependencies perfectly with minimal configuration, and adds very little overhead to each build. When I was using Make, I was doing clean builds almost every time (which took somewhere around 25s). Now, with tup, I never do clean builds, and the builds are usually essentially instantaneous. While I admit that my issues with Make were almost certainly my fault, tup has been incredibly simple to use and produced the final product I was looking for. It was definitely worth making the switch and I plan to use it for all my future projects.

My Tupfiles

I won’t try to explain the entire syntax of tup. The examples and manual do a pretty good job (and the syntax should look kind of familiar for those of you who have used Make). Take this time to go read over the examples quickly and familiarize yourself with tup – it doesn’t take very long. I will, however, provide the Tupfiles I use to build the MosquitOS kernel and bootloader (with some explanation).

Root Tuprules.tup

This file sets defines some common variables and macros for the whole project.

Root Tupfile

EFI Application Tuprules.tup

EFI Application Tupfile

Submodule Tupfile

This is a Tupfile that I place in any subdirectory that contains code I want to compile into the main project. If you want, you can add/override any of the CFLAGS at the top of the file and it will just apply to the files in that directory. Or you can create another Tuprules.tup file in that subdirectory and it will apply to all files in that subdirectory and any nested subdirectories.

Empty Project

Here are those files packaged into the appropriate file structure. If you cd into the root directory and run tup, nothing should happen, but lots of cool things are poised to happen just as soon as we add some source code.

To The Code!

Next up, we will write our first UEFI application and run it on an operating-system-less virtual machine. Onward!
